IR1 non-metallic hazardous location linear LED.
A 4 ft non-metallic linear for Class I Division 2 and Class II Division 2 areas, documented at 80 W and 10,000 lumens from two LED strips.
IR1 configurations
IR1 models and specifications.
One family, every configuration: the fixture is shown at full size, with each available configuration listed below and specified line by line in the ordering table.
Ordering data
IR1 models and specifications.
All 1 configurations of the family are specified on this page, so you can compare wattages, outputs and options side by side.
| Model | Wattage | Typical Lumens | CCT | Listings |
|---|---|---|---|---|
| IR1-4-2-LED-UNV | 80 W | 10,000 lm | 4000 K or 5000 K | UL 1598-A Marine, UL 844 C1D2 and C2D2 |
Confirm the exact configuration against the current manufacturer specification sheet before approval or purchase.
Engineering reference
Choosing the right IR1 configuration.
Confirm the area is Division 2 rather than Division 1, select 4000 K or 5000 K, and verify that the non-metallic housing and surface or suspended mounting suit the installation. The documented emergency-backup option adds -EM to the catalog number.
IR1 combines a glass-reinforced polyester housing, poured-in-place gasket, stainless-steel locking latches and high-impact acrylic diffuser for corrosive, marine, wet and damp Division 2 applications. The corrected configuration uses two 40 W LED strips producing 5,000 lumens each.
Common questions
Frequently asked questions
These answers clarify the selection process without replacing project-specific documentation.
Is more than one wattage available?
The replacement sheet documents one 4 ft configuration at 80 W and 10,000 lumens, using two 40 W LED strips rated at 5,000 lumens each.
What listings does IR1 carry?
UL 1598A Marine plus UL 844 Class I Division 2 and Class II Division 2. Confirm groups and temperature code against the specific catalog number.
Which color temperatures are documented?
The corrected specification source documents 4000 K or 5000 K for the 80 W configuration.
