Product family · High Bay
EDGE Series modular LED high bay.
The highest output high bay in the range, modular from 120 W to 600 W and reaching 96,000 lumens with a 60 °C ambient ceiling.
EDGE High Bay configurations
Every documented EDGE High Bay configuration.
One family, every configuration: the fixture is shown at full size, with each available configuration listed below and specified line by line in the ordering table.
Ordering data
Every documented EDGE High Bay configuration.
All 5 configurations of the family are specified on this page, so you can compare wattages, outputs and options side by side.
| Model | Wattage | Typical Lumens | Voltage | Optics (examples) | Operating Temp | Key Ratings |
|---|---|---|---|---|---|---|
| EL NED 120 HB | 120 W | 19,200 lm | 100 to 277 V AC, 200 to 480 V option | 22°, 30°, 45° narrow beams for focused high bay lighting | 30°C to 60°C ambient | IP66, 160 lm per W, Philips Lumileds, 5 year warranty |
| EL NED 200 HB | 200 W | 33,000 lm | 100 to 277 V AC, 200 to 480 V option | 60°, 90° medium beam optics for general warehouse aisles | 30°C to 60°C ambient | IP66, 165 lm per W, high power factor driver |
| EL NED 300 HB | 300 W | 49,500 lm | 100 to 277 V AC, 200 to 480 V option | 110°, 150° wide distributions for open areas and sports courts | 30°C to 60°C ambient | IP66, 165 lm per W, L70 greater than 150,000 hours |
| EEL NED 400 HB | 400 W | 66,000 lm | 100 to 277 V AC, 200 to 480 V option | 40×100° and 60×100° aisle optics for racked storage facilities | 30°C to 60°C ambient | IP66, 165 lm per W, aluminum alloy housing |
| EL NED 600 HB | 600 W | 96,000 lm | 100 to 277 V AC, 200 to 480 V option | 90°, 110° and 150° optics for very high mounting and large areas | 30°C to 60°C ambient | IP66, 160 lm per W, five year warranty, multiple sensor options |
Confirm the exact configuration against the current manufacturer specification sheet before approval or purchase.
Engineering reference
Selecting within the EDGE High Bay family.
Confirm the clear height and target level, since this family exists for cases the others cannot reach. Then the optic — 22° to 45° narrow beams for focused positions, 60° and 90° for general aisles. Confirm the ambient, since the 60 °C ceiling is a documented limit rather than a headline.
EDGE covers the top of the high bay range, where clear heights and target levels exceed what a single-body fixture delivers. The modular construction is what makes the 600 W configuration practical, and the 60 °C ambient rating separates it from the other high bay families.
Common questions
Useful answers before the next step.
These answers clarify the selection process without replacing project-specific documentation.
How does this differ from the EDGE high temperature family?
They are separate families sharing a name. This one is documented to 60 °C ambient for high bay duty; the high temperature EDGE is rated to 80 °C and appears under high temperature and flood and area.
What is the highest documented output?
96,000 lumens at 600 W, at 160 to 165 lumens per watt. Confirm the figure for the exact configuration ordered.
